Beam switches let one source feed several stations, with a scheduling catch
Optical switching is mature and reliable. Whether sharing saves money depends entirely on whether the stations want the beam at the same time.
A beam switch directs a single source's output into one of several delivery fibers, allowing one laser to serve multiple workstations. The technology is mature: switching is fast, losses are low, and reliability is good.
The economics depend on utilisation patterns rather than on the switch.
When sharing works
Sharing pays where stations have low individual duty cycles and their demands do not coincide. A cell where an operator loads for sixty seconds and welds for ten leaves the source idle most of the time; three such stations can share one source with little contention.
Manual welding and marking stations often fit this pattern, as do processes with long fixturing times relative to beam-on time.
When it does not
Where duty cycles are high or demands coincide, stations queue. A station waiting for the beam is a station not producing, and the productivity loss can exceed the capital saved.
Predicting contention requires knowing the actual duty cycle distribution, not the average. Two stations each using the beam thirty per cent of the time will still collide frequently if their demands are correlated — which they are if both feed the same downstream process.
The failure mode nobody plans for
A shared source is a shared point of failure. Where three stations depend on one laser, a source fault stops three stations. That is the same redundancy argument that applies to cutting machines, and it applies more sharply here because the coupling is deliberate.
Practical considerations
Switching time is typically short but non-zero, and it accumulates in high-cycle applications.
Delivery fiber length to each station adds up, and the nonlinear limits discussed for long fibers apply.
Safety interlocking becomes more complex: the system must guarantee the beam goes only where it is intended, and each station needs its own interlock chain.
Calibration per station, since each delivery path has its own losses and focus characteristics.
The evaluation
The honest test is to model station demand over a representative production period and count collisions. Shops that did this before buying generally got the configuration right; those that assumed averages would hold generally found that queueing cost more than the second source would have.
