Optical ground links have bandwidth and a weather problem
Laser links between satellites and ground carry far more data than radio. Clouds block them completely, which makes site diversity part of the system design.
Optical inter-satellite links are established technology, operating in vacuum where the medium is ideal. Extending optical communication to the ground is where the engineering becomes interesting, because the atmosphere is neither transparent nor stable.
What the link offers
Bandwidth well beyond radio frequency allocations, without spectrum licensing, with narrow beams that resist interception and interference. For downlinking Earth observation data, where volumes have grown far faster than radio capacity, the case is compelling.
The two atmospheric problems
Turbulence. Refractive index fluctuations distort the wavefront, causing beam wander, spreading and intensity scintillation. Coupling a distorted wavefront into a single-mode fibre at the receiver is inefficient and highly variable.
Adaptive optics corrects this, which is astronomy's technology applied in the opposite direction. Ground stations for optical downlinks increasingly include adaptive correction as standard.
Clouds. These are not a correction problem. An optically thick cloud blocks the link entirely, and no signal processing recovers it.
Site diversity as the answer
Because cloud cover is spatially correlated over tens of kilometres but not hundreds, a network of ground stations separated by hundreds of kilometres has a high probability that at least one is clear.
That converts the availability problem into a network design problem: how many stations, how far apart, and how to schedule traffic across them given weather forecasts and satellite passes.
The consequence is that an optical ground segment is a distributed system, not a station. That changes the cost structure substantially and is the main reason deployment has been slower than the link technology alone would suggest.
Where it is being deployed
Earth observation downlink, where data volumes justify the infrastructure. Inter-satellite backbone links in constellations, which avoid the atmosphere entirely. Deep space communication, where the gain of a narrow optical beam over a radio beam is enormous and demonstrations have already returned data from far beyond the Moon.
Terrestrial point-to-point links exist for short distances, where the same weather problem applies over a shorter path and the economics compete against fibre.
